Specification |
1. Dimension | Type A: 9500 x 2438 x 1258 mm (Extended: 12471 x 2438 x 1258 mm) Type B: 9540 x 2438 x 1258 mm (Extended: 12392 x 2438 x 1258 mm)
|
2. The chassis with a slider, can be extended approximately 2970/2850 mm by pneumatic lock pin |
3. Multiple loading models | Loaded 20' or 40' container or two empty 20' container |
Standard Configuration |
1. Axle | 11 ton, diameter 127 mm, 2/3 units |
2. Suspension | Mechanical/Air suspension |
3. King pin | 2", welding type |
4. Landing gear | 28 ton, two speeds |
5. Tire | 255/70R22.5, 16 PR, 8/12 units |
6. Rim | 8.25-22.5, 8/12 units |
7. Braking system | Chinese local brand |
8. Electrical system | Chinese local brand, 7-way split pin receptacle plug, LED light |
9. ABS | None |
10. Painting | Polyurethane, colour supplied by customer |
11. Mudguard | Chinese local brand |
Optional Configurations |
1. Air suspension | Firestone or Goodyear |
2. Lift axle system | Lift axle system |
3. ABS system Wabco | ABS system Wabco or Chinese brand |
